BULK TRANSFER / RECOVERY HOSE 15 BAR

Ideal for recovery operations of sandblasting abrasives. Used for transferring materials via suction or gravity systems i.e. tank trucks and silos. Suitable for vacuum or ducting services.

Item Specifications

CODE	INTERNAL DIAMETER		EXTERNAL DIAMETER		WORKING PRESSURE		WEIGHT
	inch	mm	inch	mm	bar	psi	ibs/ft	kg/m
TM 2546	1"	25.4	1.84	46.8	217	15	1.27	1.89
TM 3153	1 1/4"	31.8	2.09	53.2	217	15	1.46	2.18
TM 3859	1 1/2"	38.1	2.34	59.5	217	15	1.65	2.46
TM 5073	2"	50.8	2.88	73.2	150	10	2.23	3.33
TM 6385	2 1/2"	63.5	3.38	85.9	150	10	2.65	3.95
TM 7699	3"	76.2	3.92	99.6	150	10	3.35	5
TM 1012	4"	101.6	4.95	125.8	100	7	4.4	6.55

Features
Specifications

Features:

Bulk Transfer Hose is reinforced with spirally plied synthetic fabric with spring steel wire helix, for the strength needed to handle the pressure or the suction service in the transfer of bulk materials. The steel wire helix provides full suction capability, kink resistance and a path to conduct static current.
The Natural Rubber (NR)/ Poly Butadiene Rubber (PBR) blend tube provides excellent abrasion resistance, rebound and durability.

Temperature Range:

-35°C to +70°C

-31°F to +158°F

TechnicalSpecifications:

Tube

Antistatic NR/PBR rubber, smooth, black, abrasion resistant

Reinforcement

High strength polyester/nylon cord embedded with spring steel wire helix

Cover

Antistatic NR/SBR rubber, black, corrugated for flexible handling, wrapped finish, abrasion and weather resistant

Working Temperature

-35°C to +70°C
-31°F to +158°F

Factor of Safety

Factor of Safety 3:1

Branding

Bulk Transfer Hose W.P. 15 Bar / 220 Psi

Standard Length

Rolls of 10, 20, 40m / 50, 75, 100ft

Special Properties

Abrasion resistance of tube 70 ± 5mm3 according to DIN ISO 4649:2006

Standard Meets

EXCEEDS DIN ISO 4649:2006
